Quick Details

  • Products Status: Stock
  • Ports: ≥ 48
  • Transmission Rate: 10/100/1000Mbps
  • Function: LACP, POE, QoS, SNMP, Stackable, VLAN Support
  • Communication Mode: Full-Duplex
  • Certification: Cisco
  • Switch Capacity: 960-Gbps
  • Brand Name: CISCO
  • Model Number: N3K-C3548P-10G
  • Place of Origin: China (Mainland)
  • Number of EtherChannels: 24
  • Performance: 960-Gbps switching capacity
  • Number of ACL entries: 4096

Packaging & Delivery

Packaging Details Original Cisco brand sealed packing and additional carton for shipping
Delivery Time Within 1~2 days

Specifications

1.N3K-C3548P-10G=
2.Nexus 3548, 48 SFP+ ports
3.Best Quality & Fast delivery

Product Description

The Cisco Nexus3000 Series Switches are a comprehensive portfolio of 1, 10, and 40 Gigabit Ethernet switches built from a switch-on-a-chip (SoC) architecture. Introduced in April 2011, this series of switches provides line-rate Layer 2 and 3 performance and is suitable for top-of-the-rack (ToR) architecture. This series of switches has established itself as a leader in high-frequency trading (HFT), high-performance computing (HPC), and big data environments by pairing high performance and low latency with innovations in performance visibility, automation, and time synchronization.





The Cisco Nexus 3548 has the following hardware configuration:



48 fixed Enhanced Small Form-Factor Pluggable (SFP+) ports (1 or 10 Gbps)



Dual redundant, hot-swappable power supplies



Four individual, redundant, hot-swappable fans



One 1-PPS timing port, with the RF1.0/2.3 QuickConnect connector type*



Two 10/100/1000 management ports



One RS-232 serial console port



One USB port



Locator LED



Locator LED button

Specification

Cisco Nexus 3548

Cisco Nexus 3524

Physical

48 fixed SFP+ ports (1 or 10 Gbps)
Dual redundant, hot-swappable power supplies
Four individual, redundant, hot-swappable fans
One 1-PPS timing port, with the RF1.0/2.3 QuickConnect connector type*
Two 10/100/1000-Mbps management ports
One RS-232 serial console port
One USB port
Locator LED
Locator LED button
24 fixed SFP+ ports (1 or 10 Gbps); expandable to 48 ports
Dual redundant, hot-swappable power supplies
Four individual, redundant, hot-swappable fans
One 1-PPS timing port, with the RF1.0/2.3 QuickConnect connector type*
Two 10/100/1000-Mbps management ports
One RS-232 serial console port
One USB port
Locator LED
Locator LED button

Performance

960-Gbps switching capacity
Forwarding rate of 720 million packets per second (mpps)
Line-rate traffic throughput (both Layer 2 and 3) on all ports
Configurable maximum transmission units (MTUs) of up to 9216 bytes (jumbo frames)
480-Gbps switching capacity
Forwarding rate of 360 mpps
Line-rate traffic throughput (both Layer 2 and 3) on all ports
Configurable MTUs of up to 9216 bytes (jumbo frames)
